Epact Scientific Instruments of Medieval and Renaissance Europe

It can be used for the graphical solution of problems of proportion and, when fitted with sights, serves as a measuring instrument for surveying and other tasks of practical geometry. Angles between the two limbs are measured by scales on the circular arc, which also carries an incomplete table of gunnery information.

Museum of the History of Science, Oxford
Inventory number 44505
